What's New in MapleSim 2023


The MapleSim 2023 family of products offers a host of improvements in modeling, analysis, performance, and connectivity, including many that are in direct response to customer requests.

MapleSim 2023
MapleSim 2023.2

MapleSim 2023.2 provides enhancements to assist engineers when creating and using models.

  • Speed boost when running simulations. MapleSim now processes constraint projections more efficiently, so some classes of MapleSim fixed-step models run up to 40% faster. This also applies to models exported to FMI and Simulink.
  • New Hydraulics components for pressure-dependent flow. Five additional table-based components (Cartridge, Counterbalance, Pressure Reducing 3-Way, Shuttle, and Sequence Valves with Pressure-Dependent Flow) allow users to shape the pressure-flow relationship curve by using real data points when defining the valve.
  • Usability updates: Various features make MapleSim easier to use, including:
    • The Linearization App has been refreshed, improving run time and general capabilities.
    • You can now scroll sideways in large model diagrams by pressing Shift while scrolling the mouse wheel.

Additional Improvements to Add-on Products

  • The MapleSim CAD Toolbox adds support for recent software releases from NX™, Creo®, Inventor®, and other CAD tools.
  • The MapleSim Web Handling Library has additional settings for models that use variable eccentricity in rollers and wind/unwind drums, and offers new parameters to support stepwise winding.

Available to: All MapleSim 2023 users.

MapleSim Insight 2023.2

The 2023.2 release of MapleSim Insight provides a maintenance update to align with the latest updates in MapleSim, and offers a speed boost when running fixed-step FMI models created in MapleSim 2023.2 or later.

Available to: All MapleSim Insight 2023 users.

MapleSim 2023.1

The new MapleSim 2023.1 release includes various maintenance improvements and takes advantage of the recent update to the underlying Maple math engine to provide a smoother user experience.

Updates to the MapleSim Web Handling Library

The MapleSim Web Handling Library, an add-on to MapleSim, brings additional resources to better simulate your roll-to-roll processes. Using the new 2023.1 update you can:

  • Explore the results of friction on the web line with the new Variable Nip Roller component that can combine capstan friction and nip force effects.
  • Expand the scope and realism of your model by applying new options for non-linear web materials, drum eccentricity, and centrifugal forces on rollers.
  • Quickly define roller layouts by importing mass and inertia from CAD components and match the roller orientation to the physical line using the Flip Direction setting.
  • Easily manage your web components. The new release adds a simpler method of affixing roller locations, has larger S-wrap icons, and more!

Additional Improvements to Add-on Products

  • The MapleSim CAD Toolbox adds support for recent software releases from NX™, SOLIDWORKS®, Solid Edge®, Creo Parametric™, Parasolid®, and other CAD tools.
  • The MapleSim Heat Transfer Library now has new enhancements for evaluating parameters in flows, including a linear approximation technique for calculating Density and Viscosity when approaching zero flow rates, and improved calculation of the loss friction coefficient for phase change in Laminar/Turbulent flow.
  • The MapleSim Connector for FMI and B&R MapleSim Connector receive maintenance updates in response to customer requests.

Available to: All MapleSim 2023 users.

MapleSim Insight 2023.1

The 2023.1 release of MapleSim Insight provides a maintenance update to address some interface use-cases.

Available to: All MapleSim Insight 2023 users.

MapleSim 2023

MapleSim 2023 offers better performance and an easier process when using models with your engineering toolchain.

  • A new integrated compiler allows the creation of a compiled FMU without requiring the installation of a third-party compiler.
  • Simulations are faster to run due to MapleSim taking advantage of the latest advances in the Maple 2023 math engine.

Available to: MapleSim customers who were enrolled in the Maplesoft Elite Maintenance Plan at the time of its release. (Customers who were not under EMP at that time can contact Maplesoft sales to obtain an upgrade.)

MapleSim Insight 2023

MapleSim Insight 2023 provides an optimized experience when running models, resulting in faster simulation speeds for models compiled in MapleSim 2023 or later.

Available to: MapleSim Insight customers who were enrolled in the Maplesoft Elite Maintenance Plan at the time of its release. (Customers who were not under EMP at that time can contact Maplesoft sales to obtain an upgrade.)
